Tela de 8 Polegadas
Modelo: DMG10768C080_03W (Classe Comercial)
Features:
● Based on T5L ASIC 8.0 Inches, 1024xRGBx768, 16.7M Colors, IPS screen, Cost-Effective screen;
● No Touch,Resistive,Capacitive touch panel;
● UART2: TTL/CMOS,UART4: TTL/CMOS; 10Pin_1.0mm FCC Socket;
● Download with SD card or on line serial port;
●Support TTL/CMOS, the max baud rate is 3225600bps;
● DGUSⅡ/TA(Instruction set) development modes;
● With IPS Wide View Angle:85/85/85/85(L/R/U/D);
● With GUI & OS dual-core of 8015 processor , GUI core with rich controls.,the other OS core is open to the user for the second-development, via DWIN OS language or KEIL C51.
